Mfr. Part #	Stock	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	NumberofChannels	Inputs-Side1/Side2	Voltage-Isolation	CommonModeTransientImmunity(Min)	InputType	OutputType	Current-Output/Channel	DataRate	PropagationDelaytpLH/tpHL(Max)	Rise/FallTime(Typ)	Voltage-Forward(Vf)(Typ)	Current-DCForward(If)(Max)	Voltage-Supply	OperatingTemperature	MountingType
VO2631-X007T OPTOISO 5.3KV 2CH OPEN DRN 8SMD Vishay Semiconductor Opto Division	3551	3.41	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2	2/0	5300Vrms	5kV/µs	DC	Open Drain	50 mA	10MBd	100ns, 100ns	23ns, 7ns	1.42V	15mA	4.5V ~ 5.5V	-40°C ~ 100°C	Surface Mount
TLP104(E) OPTOISO 3.75KV OPEN COLL SO6-5 Toshiba Semiconductor and Storage	3963	1.51	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	3750Vrms	15kV/µs	DC	Open Collector	8 mA	1Mbps	550ns, 400ns	-	1.61V	25mA	4.5V ~ 30V	-40°C ~ 125°C	Surface Mount
6N137A-X001 OPTOISO 5KV 1CH OPEN COLL 8DIP Vishay Semiconductor Opto Division	3164	1.51	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	5000Vrms	1kV/µs	DC	Open Collector	50 mA	10MBd	75ns, 75ns	27ns, 10ns	1.35V	20mA	4.5V ~ 5.5V	-40°C ~ 85°C	Through Hole
TLP104(V4,E OPTOISO 3.75KV OPEN COLL SO6 Toshiba Semiconductor and Storage	3932	1.51	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	3750Vrms	15kV/µs	DC	Open Collector	8 mA	1Mbps	550ns, 400ns	-	1.61V	25mA	4.5V ~ 30V	-40°C ~ 125°C	Surface Mount
TLP2366(V4,E OPTOISO 3.75KV PSH PULL SO6-5 Toshiba Semiconductor and Storage	2165	1.51	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	3750Vrms	20kV/µs	DC	Push-Pull, Totem Pole	10 mA	20MBd	40ns, 40ns	15ns, 15ns	1.61V	25mA	2.7V ~ 5.5V	-40°C ~ 125°C	Surface Mount
SFH6757T OPTOISO 4KV 2CH OPEN DRAIN 8SOIC Vishay Semiconductor Opto Division	3031	3.59	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	2	2/0	4000Vrms	15kV/µs	DC	Open Drain	50 mA	10MBd	100ns, 100ns	23ns, 7ns	1.4V	20mA	4.5V ~ 5.5V	-40°C ~ 100°C	Surface Mount
VOW2611-X017T OPTOISO 5.3KV OPN COLLECTOR 8SMD Vishay Semiconductor Opto Division	2660	3.33	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	-	Active	1	1/0	5300Vrms	25kV/µs	DC	Open Collector	50 mA	10MBd	100ns, 100ns	14ns, 7ns	1.4V	20mA	4.5V ~ 5.5V	-40°C ~ 100°C	Surface Mount
ICPL2601 OPTOISOLATOR 2.5KV OPN COLL 8DIP Isocom Components 2004 LTD	2205	2.31	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	2500Vrms	1kV/µs	DC	Open Collector, Schottky Clamped	25 mA	10Mbps	75ns, 75ns	-	1.55V	20mA	7V	0°C ~ 70°C	Through Hole
EL2630-V OPTOISO 5KV OPEN COLLECTOR 8DIP Everlight Electronics Co Ltd	3048	2.37	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	2	2/0	5000Vrms	5kV/µs	DC	Open Collector	50 mA	10Mbps	100ns, 100ns	40ns, 10ns	1.4V	20mA	7V	-40°C ~ 100°C	Through Hole
ACPL-M483-000E OPTOISO 3.75KV PUSH PULL 5SO Broadcom Limited	2622	3.44	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	3750Vrms	30kV/µs	DC	Push-Pull, Totem Pole	50 mA	-	120ns, 120ns	6ns, 6ns	1.5V	10mA	4.5V ~ 30V	-40°C ~ 105°C	Surface Mount
6N137 8 PIN 10 MBITS HIGH SPEED LOGIC QT Brightek (QTB)	3969	3.67	- + Add To Cart Inquiry Now	Datasheet	Tube	Optocoupler	Active	1	1/0	5000Vrms	5kV/µs	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	37ns, 10ns	1.4V	50mA	7V	-55°C ~ 85°C	Through Hole
RV1S9213ACCSP-10YV#SC0 OPTO COUPLER IN 5PIN SSOP Renesas Electronics America Inc	3978	3.81	- + Add To Cart Inquiry Now	Datasheet	Strip	-	Active	1	1/0	5000Vrms	50kV/µs	DC	Open Collector, Schottky Clamped	15 mA	1Mbps	750ns, 500ns	-	1.56V	20mA	4.5V ~ 25V	-40°C ~ 125°C	Surface Mount
RV1S9260ACCSP-10YC#SC0 OPTO COUPLER IN 5PIN SSOP Renesas Electronics America Inc	2670	4.38	- + Add To Cart Inquiry Now	Datasheet	Strip	-	Active	1	1/0	5000Vrms	50kV/µs	DC	Push-Pull, Totem Pole	10 mA	15Mbps	60ns, 60ns	5ns, 5ns	1.55V	20mA	2.7V ~ 5.5V	-40°C ~ 125°C	Surface Mount
APS1241S 20 MBPS TYPE PHOTOIC COUPLER (TO Panasonic Electric Works	3981	5.13	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	3750Vrms	20kV/µs	DC	Push-Pull, Totem Pole	10 mA	20Mbps	55ns, 55ns	2ns, 2ns	1.6V	25mA	2.7V ~ 5.5V	-40°C ~ 105°C	Surface Mount
HCPL-7710-320E OPTOISO 5KV PUSH PULL 8DIP GW Broadcom Limited	3974	6.85	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	5000Vrms	10kV/µs	Logic	Push-Pull, Totem Pole	10 mA	12.5MBd	40ns, 40ns	13ns, 5ns	-	-	4.5V ~ 5.5V	-40°C ~ 100°C	Surface Mount
ACFL-6211T-000E OPTOISO 5KV 2CH PSH PULL SO12 Broadcom Limited	3927	9.07	- + Add To Cart Inquiry Now	Datasheet	Tube	Automotive, AEC-Q100, R²Coupler™	Active	2	1/1	5000Vrms	15kV/µs	DC	Push-Pull, Totem Pole	10 mA	15MBd	35ns, 35ns	10ns, 10ns	1.5V	20mA	3V ~ 5.5V	-40°C ~ 125°C	Surface Mount
HCPL-0720 OPTOISO 3.75KV PUSH PULL 8SO Broadcom Limited	3711	9.32	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	3750Vrms	10kV/µs	Logic	Push-Pull, Totem Pole	10 mA	25MBd	40ns, 40ns	9ns, 8ns	-	-	4.5V ~ 5.5V	-40°C ~ 85°C	Surface Mount
ACNV260E-000E OPTOISO 5KV OPEN COLLECTOR 10DIP Broadcom Limited	2775	13.19	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	5000Vrms	20kV/µs	DC	Open Collector, Schottky Clamped	50 mA	10MBd	80ns, 80ns	25ns, 10ns	1.64V	20mA	4.5V ~ 5.5V	-40°C ~ 105°C	Through Hole
HCPL-5600 OPTOISO 1.5KV OPN COLLECTOR 8DIP Broadcom Limited	2743	82.10	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	1	1/0	1500VDC	1kV/µs	DC	Open Collector, Schottky Clamped	25 mA	10MBd	100ns, 100ns	35ns, 35ns	1.5V	20mA	4.5V ~ 5.5V	-55°C ~ 125°C	Through Hole
5962-8876903FC OPTOISO 1.5KV PUSH PULL 16FLATPK Broadcom Limited	3388	213.19	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Active	4	4/0	1500VDC	1kV/µs	DC	Push-Pull, Totem Pole	15 mA	5MBd	350ns, 350ns	45ns, 10ns	1.3V	8mA	4.5V ~ 20V	-55°C ~ 125°C	Surface Mount

Total 2551 Records«Prev 1... 26 27 28 293031 32 33...128 Next»
