Mfr. Part #	Stock	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	LogicType	NumberofCircuits	NumberofInputs	Features	Voltage-Supply	Current-Quiescent(Max)	Current-OutputHighLow	LogicLevel-Low	LogicLevel-High	MaxPropagationDelay@VMaxCL	OperatingTemperature	MountingType
74AUP1G32GW,125 IC GATE OR 1CH 2-INP 5TSSOP Nexperia USA Inc.	3479	0.47	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74AUP	Active	OR Gate	1	2	-	0.8V ~ 3.6V	500 nA	4mA, 4mA	0.7V ~ 0.9V	1.6V ~ 2V	6.4ns @ 3.3V, 30pF	-40°C ~ 125°C	Surface Mount
MC74HC1G02DTT1G IC GATE NOR 1CH 2-INP 5TSOP onsemi	5607	0.48	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74HC	Active	NOR Gate	1	2	-	2V ~ 6V	1 µA	2.6mA, 2.6mA	0.5V ~ 1.8V	1.5V ~ 4.2V	17ns @ 6V, 50pF	-55°C ~ 125°C	Surface Mount
74AHC1G09W5-7 IC GATE AND OD 1CH 2-INP SOT25 Diodes Incorporated	44500	0.48	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74AHC	Active	AND Gate	1	2	Open Drain	2V ~ 5.5V	1 µA	-, 4mA	0.5V ~ 1.65V	1.5V ~ 3.85V	7.5ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
MC74VHC1G05DTT1G IC INVERTER OD 1CH 1-INP 5TSOP onsemi	1517	0.38	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74VHC	Active	Inverter	1	1	Open Drain	2V ~ 5.5V	1 µA	-, 8mA	0.5V ~ 1.65V	1.5V ~ 3.85V	7.5ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
74AUP2G04DW-7 IC INVERTER 2CH 2-INP SOT363 Diodes Incorporated	12959	0.49	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74AUP	Active	Inverter	2	2	-	0.8V ~ 3.6V	500 nA	4mA, 4mA	0.7V ~ 0.9V	1.6V ~ 2V	5.4ns @ 3.3V, 30pF	-40°C ~ 125°C	Surface Mount
SN74LVC1G38DBVR IC GATE NAND OD 1CH 2-IN SOT23-5 Texas Instruments	7414	0.38	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	NAND Gate	1	2	Open Drain	1.65V ~ 5.5V	10 µA	-, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	3.9ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
74LVC04AS14-13 IC INVERTER 6CH 1-INP 14SO Diodes Incorporated	3065	0.39	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	Inverter	6	1	-	1.65V ~ 5.5V	10 µA	24mA, 24mA	0.7V ~ 0.8V	1.7V ~ 2V	4.3ns @ 3.3V, 50pF	-40°C ~ 125°C	Surface Mount
74HC08T14-13 IC GATE AND 4CH 2-INP 14TSSOP Diodes Incorporated	4990	0.50	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74HC	Active	AND Gate	4	2	-	2V ~ 6V	20 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	15ns @ 6V, 50pF	-40°C ~ 125°C	Surface Mount
74LVC02APW,118 IC GATE NOR 4CH 2-INP 14TSSOP Nexperia USA Inc.	6535	0.39	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	NOR Gate	4	2	-	1.2V ~ 3.6V	40 µA	24mA, 24mA	0.12V ~ 0.8V	1.08V ~ 2V	4.4ns @ 3.3V, 50pF	-40°C ~ 125°C	Surface Mount
74LVC02APW,112 IC GATE NOR 4CH 2-INP 14TSSOP Nexperia USA Inc.	3422	0.00	- + Add To Cart Inquiry Now	Datasheet	Tube	74LVC	Obsolete	NOR Gate	4	2	-	1.2V ~ 3.6V	40 µA	24mA, 24mA	0.12V ~ 0.8V	1.08V ~ 2V	4.4ns @ 3.3V, 50pF	-40°C ~ 125°C	Surface Mount
74LVC1G332GW,125 IC GATE OR 1CH 3-INP 6TSSOP Nexperia USA Inc.	4241	0.51	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	OR Gate	1	3	-	1.65V ~ 5.5V	4 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	3.5ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
SN74LVC06APWR IC INVERTER OD 6CH 1-INP 14TSSOP Texas Instruments	9515	0.40	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	Inverter	6	1	Open Drain	1.65V ~ 3.6V	1 µA	-, 24mA	0.7V ~ 0.8V	1.7V ~ 2V	3.5ns @ 3.3V, 50pF	-40°C ~ 125°C	Surface Mount
NL27WZ04DTT1G IC INVERTER 2CH 2-INP 6TSOP onsemi	26872	0.41	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	27WZ	Active	Inverter	2	2	-	1.65V ~ 5.5V	1 µA	32mA, 32mA	-	-	3.6ns @ 5V, 50pF	-55°C ~ 125°C	Surface Mount
SN74LVC2GU04DBVR IC INVERTER 2CH 2-INP SOT23-6 Texas Instruments	21296	0.41	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	Inverter	2	2	-	1.65V ~ 5.5V	10 µA	32mA, 32mA	-	-	3ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
SN74LVC2G06DBVR IC INVERTER OD 2CH 2-INP SOT23-6 Texas Instruments	6070	0.41	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	Inverter	2	2	Open Drain	1.65V ~ 5.5V	10 µA	-, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	2.9ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
SN74LVC1G00DRLR IC GATE NAND 1CH 2-INP SOT5 Texas Instruments	9542	0.41	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74LVC	Active	NAND Gate	1	2	-	1.65V ~ 5.5V	10 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	4.3ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
74HC86D,653 IC GATE XOR 4CH 2-INP 14SO Nexperia USA Inc.	23308	0.41	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74HC	Active	XOR (Exclusive OR)	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	20ns @ 6V, 50pF	-40°C ~ 125°C	Surface Mount
74HC86D,652 IC GATE XOR 4CH 2-INP 14SO Nexperia USA Inc.	3086	0.00	- + Add To Cart Inquiry Now	Datasheet	Bulk,Tube	74HC	Obsolete	XOR (Exclusive OR)	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	20ns @ 6V, 50pF	-40°C ~ 125°C	Surface Mount
74HC02PW,118 IC GATE NOR 4CH 2-INP 14TSSOP Nexperia USA Inc.	2800	0.41	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	74HC	Active	NOR Gate	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	15ns @ 6V, 50pF	-40°C ~ 125°C	Surface Mount
74HC02PW,112 IC GATE NOR 4CH 2-INP 14TSSOP Nexperia USA Inc.	3166	1.00	- + Add To Cart Inquiry Now	Datasheet	Bulk,Bulk,Tube	74HC	Obsolete	NOR Gate	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	15ns @ 6V, 50pF	-40°C ~ 125°C	Surface Mount

Total 15259 Records«Prev 1 2 3 4 5 678 9 10...763 Next»
