Mfr. Part #	Stock	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	NumberofChannels	Inputs-Side1/Side2	Voltage-Isolation	CommonModeTransientImmunity(Min)	InputType	OutputType	Current-Output/Channel	DataRate	PropagationDelaytpLH/tpHL(Max)	Rise/FallTime(Typ)	Voltage-Forward(Vf)(Typ)	Current-DCForward(If)(Max)	Voltage-Supply	OperatingTemperature	MountingType
6N137V LOGIC IC OUTPUT OPTOCOUPLER Fairchild Semiconductor	2794	0.61	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Obsolete	1	1/0	2500Vrms	10kV/µs (Typ)	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.4V	50mA	4.5V ~ 5.5V	-40°C ~ 85°C	Through Hole
6N137SD LOGIC IC OUTPUT OPTOCOUPLER Fairchild Semiconductor	3216	0.87	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Obsolete	1	1/0	2500Vrms	10kV/µs (Typ)	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.4V	50mA	4.5V ~ 5.5V	-40°C ~ 85°C	Surface Mount
FOD0738 LOGIC IC OUTPUT OPTOCOUPLER Fairchild Semiconductor	3918	3.27	- + Add To Cart Inquiry Now	Datasheet	Box	-	Obsolete	2	2/0	2500Vrms	25kV/µs	DC	Push-Pull, Totem Pole	2 mA	15MBd	60ns, 60ns	12ns, 8ns	1.45V	20mA	4.5V ~ 5.5V	-40°C ~ 100°C	Surface Mount
FOD0738R1 LOGIC IC OUTPUT OPTOCOUPLER Fairchild Semiconductor	3906	3.28	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Obsolete	2	2/0	2500Vrms	25kV/µs	DC	Push-Pull, Totem Pole	2 mA	15MBd	60ns, 60ns	12ns, 8ns	1.45V	20mA	4.5V ~ 5.5V	-40°C ~ 100°C	Surface Mount
HCPL2630SDV LOGIC IC OUTPUT OPTOCOUPLER, 2-E Fairchild Semiconductor	2642	1.02	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Active	2	2/0	2500Vrms	10kV/µs (Typ)	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.4V	30mA	4.5V ~ 5.5V	-40°C ~ 85°C	Surface Mount
HCPL2631V LOGIC IC OUTPUT OPTOCOUPLER, 2-E Fairchild Semiconductor	2415	1.11	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Active	2	2/0	2500Vrms	5kV/µs	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.4V	30mA	4.5V ~ 5.5V	-40°C ~ 85°C	Through Hole
HCPL2630V LOGIC IC OUTPUT OPTOCOUPLER, 2-E Fairchild Semiconductor	2147	1.21	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Active	2	2/0	2500Vrms	10kV/µs (Typ)	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.4V	30mA	4.5V ~ 5.5V	-40°C ~ 85°C	Through Hole
HCPL0601R2 HIGH SPEED-10MBIT/S LOGIC GATE O Fairchild Semiconductor	2375	1.31	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Active	1	1/0	3750Vrms	10kV/µs	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.75V (Max)	50mA	4.5V ~ 5.5V	-40°C ~ 85°C	Surface Mount
FOD0720R2 HIGH CMR, 25MBIT/SEC LOGIC GATE Fairchild Semiconductor	3710	1.85	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Active	1	1/0	3750Vrms	20kV/µs	Logic	Push-Pull, Totem Pole	10 mA	25Mbps	40ns, 40ns	5ns, 4.5ns	-	-	4.5V ~ 5.5V	-40°C ~ 100°C	Surface Mount
FOD8163SD AC IN-DARLINGTON OUT OPTOCOUPLER Fairchild Semiconductor	3424	0.19	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Obsolete	1	-	5000Vrms	-	AC, DC	Darlington	80 mA	-	-	60µs, 53µs	1.2V	50mA	-	-30°C ~ 100°C	Surface Mount
HCPL0600V LOGIC IC OUTPUT OPTOCOUPLER Fairchild Semiconductor	3992	1.14	- + Add To Cart Inquiry Now	Datasheet	Box	-	Obsolete	1	1/0	3750Vrms	5kV/µs	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.75V (Max)	50mA	4.5V ~ 5.5V	-40°C ~ 85°C	Surface Mount
HCPL2611V LOGIC IC OUTPUT OPTOCOUPLER Fairchild Semiconductor	3686	1.23	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Obsolete	1	1/0	2500Vrms	10kV/µs	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.4V	50mA	4.5V ~ 5.5V	-40°C ~ 85°C	Through Hole
FOD2200 LOGIC IC OUTPUT OPTOCOUPLER Fairchild Semiconductor	502	1.87	- + Add To Cart Inquiry Now	Datasheet	Tube	-	Obsolete	1	1/0	5000Vrms	10kV/µs	DC	Tri-State	25 mA	2.5MBd	300ns, 300ns	80ns, 25ns	1.4V	10mA	4.5V ~ 20V	-40°C ~ 85°C	Through Hole
6N137SVM HIGH SPEED 10MBIT/S LOGIC GATE O Fairchild Semiconductor	940	0.72	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Active	1	1/0	5000Vrms	10kV/µs (Typ)	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	30ns, 10ns	1.45V	50mA	4.5V ~ 5.5V	-40°C ~ 100°C	Surface Mount
HCPL2530 LOGIC IC OUTPUT OPTOCOUPLER, 2-E Fairchild Semiconductor	746	0.74	- + Add To Cart Inquiry Now	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
HCPL2601 10 MBIT/S SINGLE-CHANNEL HIGH SP Fairchild Semiconductor	500	0.86	- + Add To Cart Inquiry Now	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
HCPL2631 LOGIC IC OUTPUT OPTOCOUPLER, 2-E Fairchild Semiconductor	799	1.14	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Obsolete	2	2/0	2500Vrms	5kV/µs	DC	Open Collector, Schottky Clamped	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.4V	30mA	5.5V	-40°C ~ 85°C	Through Hole
HCPL2601V 10 MBIT/S SINGLE-CHANNEL HIGH SP Fairchild Semiconductor	2687	1.21	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Active	1	1/0	2500Vrms	5kV/µs	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.4V	50mA	4.5V ~ 5.5V	-40°C ~ 85°C	Through Hole
HCPL0601V HIGH SPEED-10MBIT/S LOGIC GATE O Fairchild Semiconductor	3805	1.31	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Active	1	1/0	3750Vrms	10kV/µs	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.75V (Max)	50mA	4.5V ~ 5.5V	-40°C ~ 85°C	Surface Mount
HCPL2611SV 10 MBIT/S SINGLE-CHANNEL HIGH SP Fairchild Semiconductor	2967	1.41	- + Add To Cart Inquiry Now	Datasheet	Bulk	-	Active	1	1/0	2500Vrms	10kV/µs	DC	Open Collector	50 mA	10Mbps	75ns, 75ns	50ns, 12ns	1.4V	50mA	4.5V ~ 5.5V	-40°C ~ 85°C	Surface Mount
