Mfr. Part #	Stock	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	FrequencyRange	Type	CurrentRating(Amps)	Inductance	ET(Volt-Time)	TurnsRatio-Primary:Secondary	CurrentRatio	DCResistance(DCR)	Ratings	MountingType	Size/Dimension	Height-Seated(Max)
PCS020-EE05730S CURRENT SENSE TRANSF 20A 730UH Bourns Inc.	3456	5.37	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	PCS	Active	1MHz	Invasive	20 A	730 mH	32.4VµS	1:60	60:1	7mOhm Primary, 1.98Ohm Secondary Max	-	Surface Mount	0.245 L x 0.235 W (6.22mm x 5.97mm)	0.209 (5.31mm)
PCS020-EE0503KS CURRENT SENSE TRANSF 20A 3000UH Bourns Inc.	2870	5.37	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	PCS	Active	1MHz	Invasive	20 A	3 H	67.5VµS	1:125	125:1	7mOhm Primary, 7Ohm Secondary Max	-	Surface Mount	0.245 L x 0.235 W (6.22mm x 5.97mm)	0.209 (5.31mm)
PCS040-EF1305KS CURRENT SENSE TRANSF 40A 5440UH Bourns Inc.	300	5.13	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	PCS	Active	1MHz	Invasive	40 A	5.44 mH	203.2VµS	1:80	80:1	1mOhm Primary, 1.15Ohm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
PCS020-EE05081S CURRENT SENSE TRANSF 20A 81UH Bourns Inc.	3982	5.37	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	PCS	Active	1MHz	Invasive	20 A	81 mH	10.8VµS	1:20	20:1	7mOhm Primary, 400mOhm Secondary Max	-	Surface Mount	0.245 L x 0.235 W (6.22mm x 5.97mm)	0.209 (5.31mm)
PCS020-EE05320S CURRENT SENSE TRANSF 20A 320UH Bourns Inc.	3300	5.37	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	PCS	Active	1MHz	Invasive	20 A	320 mH	21.6VµS	1:40	40:1	7mOhm Primary, 1.14Ohm Secondary Max	-	Surface Mount	0.245 L x 0.235 W (6.22mm x 5.97mm)	0.209 (5.31mm)
7201 SENSOR CURRENT 10A UNI TH Bourns Inc.	2170	0.00	- + Add To Cart Inquiry Now	Datasheet	Bulk	7200	Obsolete	-	-	-	-	-	-	-	-	-	-	0.748 L x 0.433 W (19.00mm x 11.00mm)	0.791 (20.10mm)
7202 SENSOR CURRENT 20A UNI TH Bourns Inc.	3746	0.00	- + Add To Cart Inquiry Now	Datasheet	Bulk	7200	Obsolete	-	-	-	-	-	-	-	-	-	-	0.748 L x 0.433 W (19.00mm x 11.00mm)	0.791 (20.10mm)
7203 SENSOR CURRENT 35A UNI TH Bourns Inc.	2220	0.00	- + Add To Cart Inquiry Now	Datasheet	Bulk	7200	Obsolete	-	-	-	-	-	-	-	-	-	-	0.748 L x 0.433 W (19.00mm x 11.00mm)	0.791 (20.10mm)
PCS020-EE05180S CURRENT SENSE TRANSF 20A 180UH Bourns Inc.	2451	2.64	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR)	PCS	Active	1MHz	Invasive	20 A	180 mH	16.2VµS	1:30	30:1	7mOhm Primary, 870mOhm Secondary Max	-	Surface Mount	0.245 L x 0.235 W (6.22mm x 5.97mm)	0.209 (5.31mm)
PCS040-EF13340S CURRENT SENSE TRANSF 40A 340UH Bourns Inc.	3011	2.87	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR)	PCS	Active	1MHz	Invasive	40 A	340 µH	50.8VµS	1:20	20:1	1mOhm Primary, 180mOhm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
PCS040-EF1304KS CURRENT SENSE TRANSF 40A 4160UH Bourns Inc.	3704	2.87	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR)	PCS	Active	1MHz	Invasive	40 A	4.16 mH	177.8VµS	1:70	70:1	1mOhm Primary, 1Ohm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
PCS020-EE05980S CURRENT SENSE TRANSF 20A 980UH Bourns Inc.	3487	2.64	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR)	PCS	Active	1MHz	Invasive	20 A	980 mH	37.8VµS	1:70	70:1	7mOhm Primary, 4.75Ohm Secondary Max	-	Surface Mount	0.245 L x 0.235 W (6.22mm x 5.97mm)	0.209 (5.31mm)
PCS020-EE05500S CURRENT SENSE TRANSF 20A 500UH Bourns Inc.	2324	2.64	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR)	PCS	Active	1MHz	Invasive	20 A	500 mH	27VµS	1:50	50:1	7mOhm Primary, 1.5Ohm Secondary Max	-	Surface Mount	0.245 L x 0.235 W (6.22mm x 5.97mm)	0.209 (5.31mm)
PCS040-EF1308KS CURRENT SENSE TRANSF 40A 8500UH Bourns Inc.	3160	2.87	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR)	PCS	Active	1MHz	Invasive	40 A	8.5 mH	254VµS	1:100	100:1	1mOhm Primary, 1.45Ohm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
PCS040-EF1313KS CURRENT SENSE TRANSF 40A 13300UH Bourns Inc.	2825	2.87	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR)	PCS	Active	1MHz	Invasive	40 A	13.3 mH	317.5VµS	1:125	125:1	1mOhm Primary, 1.85Ohm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
PCS040-EF1302KS CURRENT SENSE TRANSF 40A 2120UH Bourns Inc.	2647	2.87	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR)	PCS	Active	1MHz	Invasive	40 A	2.12 mH	127VµS	1:50	50:1	1mOhm Primary, 705mOhm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
PCS040-EF13760S CURRENT SENSE TRANSF 40A 760UH Bourns Inc.	2758	2.87	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR)	PCS	Active	1MHz	Invasive	40 A	760 µH	76.2VµS	1:30	30:1	1mOhm Primary, 265mOhm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
PCS040-EF1301KS CURRENT SENSE TRANSF 40A 1360UH Bourns Inc.	300	5.13	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	PCS	Active	1MHz	Invasive	40 A	1.36 mH	101.6VµS	1:40	40:1	1mOhm Primary, 560mOhm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
PCS040-EF1319KS CURRENT SENSE TRANSF 40A 19200UH Bourns Inc.	300	5.13	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	PCS	Active	1MHz	Invasive	40 A	19.2 mH	381VµS	1:150	150:1	1mOhm Primary, 2.25Ohm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
PCS040-EF1334KS CURRENT SENSE TRANSF 40A 34000UH Bourns Inc.	300	5.13	- + Add To Cart Inquiry Now	Datasheet	Tape & Reel (TR),Cut Tape (CT)	PCS	Active	1MHz	Invasive	40 A	34 mH	508VµS	1:200	200:1	1mOhm Primary, 4.06Ohm Secondary Max	-	Surface Mount	-	0.413 (10.50mm)
